Description

HA17393B is dual comparators designed for general purpose, especially for power control systems. This IC operates from a single power-supply voltage over a wide range of voltages. Operation from split power supply current is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. These comparators have the merit which ground is included in the common-mode input voltage range at a single-voltage power supply operation.

Features

•  Wide range of supply voltage
   Single supply: 2 V to 36 V, Dual supplies: ±1 V to ±18 V
•  Very low supply current: 0.6 mA
•  Small input bias current: 25 nA
•  Small input offset voltage: 2 mV
•  Common mode input voltage range includes ground.
•  Low output saturation voltage: 200 mV at 4 mA
•  Open collector output
•  Package outline available in Pb free lead frame:
   DP-8
   SOP-8 (JEITA)
   SOP-8 (JEDEC）

Applications

•  Battery charger
•  Cordless telephone
•  Switching power supply
•  DC/DC module
•  PC motherboard
•  Communication equipment

Ordering Information
