Part Name

Package Type

Package Code

(Previous Code)

Package

Abbreviation

Taping Abbreviation

(Quantity)

HD74HC238P

DILP-16 pin

PRDP0016AE-B

(DP-16FV)

P

—

HD74HC238FPEL

SOP-16 pin (JEITA)

PRSP0016DH-B

(FP-16DAV)

FP

EL (2,000 pcs/reel)

HD74HC238RPEL

SOP-16 pin (JEDEC)

PRSP0016DG-A

(FP-16DNV)

RP

EL (2,500 pcs/reel)

Item

Symbol

Ratings

Unit

Supply voltage range

VCC

–0.5 to 7.0

V

Input / Output voltage

VIN, VOUT

–0.5 to VCC  +0.5

V

Input / Output diode current

IIK, IOK

±20

mA

Output current

IO

±35

mA

VCC, GND current

ICC  or IGND

±75

mA

Power dissipation

PT

500

mW

Storage temperature

Tstg

–65 to +150

°C
