Ultra-low power consumption technology

• V DD = single power supply voltage of 1.6 to 5.5 V

• HALT mode

• STOP mode

High-speed wakeup from the STOP mode is possible.

• SNOOZE mode

RL78 CPU core

• CISC architecture with 3-stage pipeline

• Minimum instruction execution time: Can be changed from high speed (0.03125 µs @ 32 MHz operation with the

high-speed on-chip oscillator clock) to ultra-low speed (30.5 µs @ 32.768 kHz operation with the subsystem clock)

• Multiply/divide/multiply & accumulate instructions are supported.

• Address space: 1 MB

• General-purpose registers: (8-bit register × 8) × 4 banks

• On-chip RAM: 12 to 48 KB

Code flash memory

• Code flash memory: 96 to 768 KB

• Block size: 2 KB

• Prohibition of block erase and rewriting (security function)

• On-chip debugging

• Self-programming (with boot swapping and flash shield window)

Data flash memory

• Data flash memory: 8 KB

• Background operation (BGO): Instructions can be executed from the program memory while rewriting the data flash

memory.

• Number of rewrites: 1,000,000 times (typ.)

High-speed on-chip oscillator

• Select from 32 MHz, 24 MHz, 16 MHz, 12 MHz, 8 MHz, 6 MHz, 4 MHz, 3 MHz, 2 MHz, or 1 MHz

• High accuracy: ±1.0% (V DD = 1.8 to 5.5 V, T A = -20 to +85°C)

Middle-speed on-chip oscillator

• Select from 4 MHz, 2 MHz, or 1 MHz (with adjustability)

Low-speed on-chip oscillator

• 32.768 kHz (typ.) (with adjustability)
